Sprinklers

1453 TS6011 Adjustable Plastic Sprinkler

Product code:

₺1,000.00

The 1453 adjustable plastic sprinkler (TS6011) is used for agricultural irrigation. 20–29 m throw radius at 2–5 bar, 1½” water inlet, 30°–360° arc.

Quote on WhatsApp
  • Manufacturer warranty and spare parts support
  • UV-stabilised virgin raw material
  • Fast domestic and export shipping

The 1453 adjustable plastic sprinkler (TS6011) is used for agricultural irrigation. It is made from material resistant to impact, sunlight and alkaline water; the body is long-lasting and the mechanism has a stainless steel spring.

Features

  • The jet breaker pin produces strong droplets.
  • Does not batter the soil or plant leaves.
  • Even water distribution without puddling.
  • 1½″ female threaded connection.

Applications

  • Tall crops: clover, wheat, corn, cotton, sunflower, sugar cane, pineapple
  • Field crops: potato, onion, beet
  • Turf: football stadiums, hippodromes, stud farms, feedlots and pastures
  • Industry: dust suppression in factories, coal mines and stone quarries

Technical specifications

Working pressure2–5 bar
Water inlet1½"
Average flow rate5–25 m³/h
Throw radius20–29 m
Arc adjustment30°–360°
Stand inlet pipe size1½"
Stand outlet pipe size1½"
Nozzle sizes (mm)10–12–14–16

Performance data

Nozzle (mm)Pressure (bar)Flow (m³/h)Max. throw radius (m)
STANDART25.116
35.917.5
47.219.5
58.421
10 MM27.818
39.521
41123
512.424.5
12 MM210.119.5
312.422
414.325
516.127.5
14 MM212.920.5
315.823.5
418.326
520.528.5
16 MM21621
319.624
422.726.5
524.829

Values show the maximum throw radius measured in still air.

Packaging

CodeContentsPer boxGross weightBox size
34161453 TS6011 adjustable plastic sprinkler106.65 kg37×41×26 cm
  • No minimum order quantity for this product.
  • Orders are shipped from our Istanbul factory. Export shipments by pallet or container on request.
  • Prices are wholesale list prices excluding VAT unless stated otherwise.
